High-speed insertion at 0.14 sec/component ensures highly efficient, high-quality production.

Realized high speed insertion

• Radial insertion machine using lead wire V-cut method realizes high-speed insertion with 0.14 s/component
• Select specification from 5 different pitches

Highly efficient production

• The fixed component feeder unit and the out-of-component detection feature allows replenishing components beforehand for long-term non-stop operation.
• For 80 station specification, the components supply system is divided into 2 parts, enabling equipment operation during pre-setup and components replacement based on the production format, improving the operation rate.
• An auto-recovery function is provided capable of handling loading errors automatically for non-stop production for a long time.

Enlargement function option

• Large-size PCB support option allows hole recognition and insertion up to PCB size of Max. 650 mm x 381 mm.
• 2 PCB transfer option can decrease PCB loading time by half and increase productivity.
